HIOKI IM3570 Impedance Analyzer: Advanced Precision for Professional Testing

The HIOKI IM3570 Impedance Analyzer is a high-performance electrical measurement instrument designed for engineers, electronics manufacturers, research laboratories, and quality control professionals. Combining the capabilities of a precision LCR meter and an advanced impedance analyzer, this versatile instrument provides accurate and reliable characterization of electronic components across a wide frequency spectrum. For additional component testing solutions, explore the HIOKI IM3536 LCR Meter.

With a measurement frequency range of 4 Hz to 5 MHz and basic impedance accuracy of ±0.08% rdg., the HIOKI IM3570 is an excellent solution for demanding applications that require precise electrical measurements, repeatable results, and efficient testing workflows.

Key Measurement Capabilities of the HIOKI IM3570 Impedance Analyzer

One of the most important advantages of this instrument is its three versatile measurement modes. These modes allow users to perform different types of electrical characterization without requiring multiple measurement devices.

• LCR Mode: Measures inductance, capacitance, resistance, dissipation factor, and quality factor for routine component testing.
• Analyzer Mode: Performs frequency sweeps and measurement-level sweeps to evaluate electrical characteristics under different conditions.
• Continuous Measurement Mode: Enables continuous monitoring of electrical parameters for production testing and long-term evaluation.

The instrument measures impedance (Z), admittance (Y), phase angle (θ), equivalent series resistance (ESR), DC resistance (Rdc), reactance (X), conductance (G), susceptance (B), inductance, and capacitance.

Exceptional Accuracy and Wide Frequency Range

The HIOKI IM3570 Impedance Analyzer delivers reliable measurements with basic accuracy specifications of ±0.08% for impedance and ±0.05° for phase angle.

Its extensive frequency range of 4 Hz to 5 MHz makes it suitable for evaluating a wide variety of electronic components, including capacitors, inductors, coils, transformers, and piezoelectric elements. For specialized impedance measurement applications, consider the HIOKI IM3590 Chemical Impedance Analyzer, another solution in the Hioki measurement range.

The instrument also supports adjustable measurement signal levels. Users can configure voltage or constant-current measurement modes according to their testing requirements. This flexibility is particularly valuable when evaluating components whose electrical characteristics change depending on the applied signal.

Advanced Functions for Industrial Quality Control

Beyond conventional impedance measurements, the IM3570 incorporates several advanced functions that improve testing efficiency and repeatability.

The DC bias measurement function allows electrical components to be evaluated under applied DC voltage or current conditions. This is particularly useful when testing components whose impedance characteristics vary with bias conditions.

The Comparator function enables automatic pass/fail decisions based on predefined measurement limits. Additionally, the BIN classification function sorts components into predefined categories, helping manufacturers streamline inspection procedures and improve production efficiency.

Panel loading and saving also allow operators to store and recall measurement configurations, reducing setup time and minimizing configuration errors.

For applications requiring highly accurate low-resistance measurements, discover the HIOKI RM3545A Resistance Meter.

Connectivity and Automation Integration

The HIOKI IM3570 Impedance Analyzer offers comprehensive communication interfaces for integration into modern testing environments.

Available interfaces include USB communication, LAN, RS-232C, GP-IB, and EXT I/O (handler). These connections support external control, measurement data transfer, and automated component testing.

A 5.7-inch color TFT display provides a clear interface for viewing measurement results and configuring test parameters. Its representative measurement time of just 0.5 ms at 100 kHz in FAST mode with the display off makes it particularly attractive for high-speed testing applications.

For other professional electrical measurement solutions, visit the Hioki Test and Measurement Instruments collection.

Applications of the HIOKI IM3570

The instrument is suitable for a variety of professional applications, including:

• Electronic component manufacturing and inspection.
• Capacitor ESR and dissipation factor testing.
• Inductor and transformer L-Q characterization.
• Piezoelectric element resonance analysis.
• Research and development in electronics and materials science.
• Automated production testing and component classification.

For specialized electrical insulation and material resistance testing, you can also explore the HIOKI SM-8213 Super Megohmmeter.

Why Buy the HIOKI IM3570 from TPT24?

Choosing a reliable supplier is essential when investing in professional measurement equipment. TPT24 provides access to Hioki testing instruments for industrial, laboratory, and engineering applications.

Before purchasing, customers can contact the TPT24 team to confirm product availability, delivery arrangements, warranty conditions, and the appropriate measurement accessories.

Order the HIOKI IM3570 Impedance Analyzer from TPT24 to equip your laboratory or production facility with a versatile measurement solution for precision electrical characterization.
