Endress+hauser T 150 Proline t-mass thermal mass flowmeter

Description

Endress+hauser T 150 Proline t-mass thermal mass flowmeter

Proline t-mass T 150 is an Endress+Hauser thermal mass flowmeter engineered specifically for liquid applications where reliable monitoring and trending matter most. Because Proline t-mass T 150 measures independently of electrical conductivity, it is a strong choice for processes where conductivity can vary, drift, or be intentionally low.

In many plants, teams want a single flow measurement approach across different water qualities and other liquids. Therefore, this device helps standardize liquid mass flow monitoring without relying on conductive properties that can limit other technologies.

Key features and benefits of Proline t-mass T 150

Proline t-mass T 150 brings direct mass flow measurement to a wide range of liquid duties, supporting stable operation and consistent data for operational decisions. It is designed to deliver high repeatability and good linearity, which is especially important for trending, balancing utilities, and detecting changes over time.

In addition, this device is built for practical day-to-day operation. User-defined settings can be stored on the display and transferred between devices, which helps reduce commissioning effort and supports consistent configuration across multiple instruments in the same facility.

Conductive and non-conductive liquids in one instrument concept

Because this device is conductivity independent, it can monitor liquids that may challenge conductivity-based approaches. This includes different water types and also non-water liquids used for process support and monitoring tasks.

As a result, maintenance and training can be simplified. Plants can deploy Proline t-mass T 150 across multiple utility and process lines while keeping a consistent operating concept.

Proline t-mass T 150 technical highlights for modern integration

this devicecombines a compact transmitter with outputs that fit common industrial architectures. It supports 24 V DC power, enabling straightforward integration into many cabinet and skid designs.

For signal and communication, this device provides 4-20 mA HART for process control connectivity. It also offers pulse/frequency/switch output, giving additional flexibility for totalization, simple alarming, or interface requirements in distributed systems.

High process safety with integrated temperature compensation

Thermal mass measurement in liquids can be influenced by temperature changes, so this device uses integrated temperature compensation to help stabilize measurement behavior. This supports consistent mass flow values under varying operating temperatures and contributes to reliable monitoring performance.

Consequently, this device is well suited when the goal is dependable trending rather than custody transfer. It provides actionable flow data that helps operators detect deviations early and react before they become costly issues.

Typical applications and industries for Proline t-mass T 150

this device is positioned for a broad set of water-related applications, including utility monitoring and process water tracking. It can be used in municipal and industrial water systems where operators need stable flow insight without being impacted by conductivity variation.

In industrial facilities, Proline t-mass T 150 can support cooling water monitoring, process water consumption tracking, and general liquid utilities trending. Because it is conductivity independent, it can also be applied where water quality is changed by treatment steps, dilution, or purification.

Hygienic option for clean processes

For applications that demand hygienic design practices, this device offers a hygienic sensor version. It also supports SIP cleaning capability up to 130 °C, aligning with typical clean-utility needs in regulated environments.

This device relevant for clean water duties in food and beverage operations and in pharmaceutical environments where cleaning procedures and hygienic practices are essential for product protection.

Installation and commissioning advantages with Proline t-mass T 150

this device is designed with a compact transmitter footprint, which is helpful when piping areas are congested or retrofit space is limited. This supports practical installation planning and easier mechanical integration in existing plants.

Commissioning is supported by guided operating menus, helping teams configure the instrument more quickly and consistently. In addition, automatic data recovery for servicing supports maintainability by protecting key configuration and operating data over the instrument lifecycle.

Why buy from TPT24

When you source this device from TPT24, you work with a specialist supplier focused on instrumentation and measurement equipment. TPT24 supports customers with technical consultation and quotation support, helping you select the right configuration for your liquid application.

TPT24 also focuses on supplying genuine Endress+Hauser products for industrial measurement needs. That means your Proline t-mass T 150 project can move forward with clear documentation expectations and a procurement process built around technical accuracy.

Conclusion and next step

If you need conductivity-independent liquid mass flow monitoring in a compact, integration-ready design, Proline t-mass T 150 is a practical Endress+Hauser solution for stable trending and process insight. Request a quote at tpt24 today for Proline t-mass T 150 and align your selection with TPT24 technical consultation.
